400G QSFP-DD Loopback
400G QSFP-DD Electrical Passive Loopback
Hot Pluggable, 0~5dB Internal Attenuation, 0~5W Power Consumption
| Part Number | Data Rate | Internal Attenuation | Power Consumption | Temperature | Remark | Datasheet |
|---|---|---|---|---|---|---|
| FQDD-TX-XLB-xx-xx | 400G | 0~5dB | 0~5W | -40~85°C | QSFP-DD-400G-Loopback | |
- Board and System Level Testing
- System Test and Measurement
- Switch / Router Chamber Test
- Power Consumption Validation
- Compliant with QSFP-DD MSA
- Compliant with IEEE 802.3bs 400GAUI-8 and 200GAUI-8 Interface
- Electrical Data Rate up to 56Gbps per Lane
- Hot Pluggable QSFP-DD footprint
- 2-wire interface for management
- Single 3.3V power supply
- Different Option for Internal Attenuation and Power Consumption
- RoHS compliant
